High-resolution WUXGA OLED microdisplays Evaluation-Kit

Evaluation-Kit: High-resolution WUXGA OLED microdisplays

Large OLED microdisplay (resolution 1920 × 1200 pixels, 120 fps, 1 inch screen diagonal).

These evaluation kits include microdisplays which, due to their size and resolution, are particularly suitable for VR applications.

  • Display diagonal: 1 inch
  • Resolution: 1920 × 1200 pixels
  • Pixel pitch 11 μm (2300 ppi)
  • High frame rates up to 120 Hz
  • High contrast ratio of >100 000 : 1 at extraordinary low power consumption
  • Supplied with control electronics (via HDMI)
  • Power supply via USB



JUCW1010 UUGL1220
full color display with 24 Bit color depth monochrome green display with 8 Bit color depth
