TSN IP Core making devices fit for real-time Ethernet

Press Release / November 19, 2018

Time-Sensitive Networking (TSN) is a set of standards allowing for the timed and prioritized transmission of real-time critical messages over standard Ethernet hardware. With the TSN IP Core, developers at Fraunhofer IPMS provide equipment manufacturers and operators the opportunity to make their devices fit for new TSN standards. Fraunhofer IPMS will be presenting the possibilities of the TSN IP Core to members of the specialist public in Hall 7a, Booth 246 at this year's SPS IPC Drives event from 27-29 November in Nuremberg.

© Fraunhofer IPMS
The TSN standard allows real-time data transmission over Ethernet.

Already a reality in many companies, intelligent Industry 4.0 automation systems connect increasingly more sensors, machines, and control units with each other. These systems must not only handle ever larger amounts of data, but especially in case of control systems and sensors/actuators, must transmit data with precise timing – often in real time. Many manufacturers of industrial devices, therefore, are currently in the process of making their devices TSN-capable. Because Ethernet network technology typically found throughout industrial automation is not designed for difficult real-time transmission due to latencies and non-deterministic delays in overload situations, Fraunhofer IPMS provides companies support with a so-called IP Core.

Dr. Frank Deicke, Head of the Fraunhofer IPMS Research Group, states, »Our TSN IP Core helps producers and operators of manufacturing and process automation equipment who aim to extend their network devices to meet Time-Sensitive Networking (TSN) standards.« He explains, »Ethernet TSN is advantageous in that it allows data packets with real-time requirements to be prioritized ahead of less time-critical messages, and time-controlled and deterministically transmitted over standard Ethernet hardware throughout widely ramified networks. Vendor-specific real-time field buses that require specialized hardware support, that are not compliant with IEEE 802.1 and 802.3 standards, and that often interfere with each other are therefore unnecessary.«

The Fraunhofer IPMS TSN IP CORE includes hardware modules for time synchronization (IEEE 802.1AS) and data stream management (Traffic Shaping) according to IEEE 802.1 Qav and 802.1Qbv standards as well as a dedicated Ethernet MAC for low latency. Available as a synthesizable source code or a netlist, the IP Core uses standard AMBA^® or Avalon^® interfaces to facilitate integration with your own circuits and FPGA solutions.

At the international SPS IPC Drives trade fair for intelligent automation being held from 27-29 November 2018 in Nuremberg, Fraunhofer IPMS developers will present the TSN IP Core together with industrial-grade solutions as well as customer evaluation kits for wireless optical data transmission (Li-Fi) for smaller and larger ranges. Applications of the maintenance-free and battery-less RFID Sensor Transponder will also be demonstrated.

Visitors to the 2018 SPS IPC Drives can find the Fraunhofer IPMS exhibition at Booth 246 in Hall 7a. In addition, Fraunhofer IPMS will feature TSN-capable terminals based on the TSN IP Core at the Industrial Internet Consortium (IIC) Demo Wall (Booth 360, Hall 6), as well as at the Labs Network Industry 4.0 (LNI) Demo Wall (Booth 347, Hall 5). We look forward to seeing you all there!

The Fraunhofer Institute for Photonic Microsystems IPMS with its more than 300 employees is dedicated to top-level applied research and development in the fields of photonic systems, microsystems technologies, nanoelectronic technologies and wireless microsystems. Innovative processes and products which are based upon our various technologies can be found in all large markets – such as information and communication technologies, consumer products, automobile technology, semi-conductor technology, measurement and medical technology. More than 50 percent of our annual operating expense of 39 million euros is financed by direct commissions from industry. Regarding MEMS based and photonic systems we offer complete solutions: From conception to component right up to complete systems. This includes sample and pilot production in our 1500 m² (15,000 ft²) clean room (ISO 14644-1 class 4) with qualified processes. Additionally, in the area of nanoelectronics our business unit Center Nanoelectronic Technologies CNT provides services in the field of nano- and microelectronics with functional electronic materials, processes and systems, device and integration, maskless lithography and analytics. Another 800 m² of clean room space (ISO 14644-1 class 6) is available for this purpose. In order to meet the demands of our customers,our institute is certified according to the standard DIN EN 9001:2015.
